Tipper full trailer truck material use the high strength steel Q345B, and the upper plate is 16mm, middle 10mm, low plate is 18mm. The cargo box thickness is bottom 8mm, size 6mm.
Tipper full trailer truck material use the high strength steel Q345B, and the upper plate is 16mm,
middle 10mm, low plate is 18mm. The cargo box thickness is bottom 8mm, size 6mm. and hydraulic
lift is adopt the HYVA brand. Also tire model have the radial, tubeless such as the 12.00R20, 12R22.5
etc. It's usually used application with wheel loader in the mining site or other site.
The Main Specification For The Tipper Full Trailer Truck.
Axles: 3x13 Tons, FUWA or BPW brand.
Main Material: Q345B, high strength steel
Tractor Pin: JOST brand, 50# or 90#
Brake System: ABS+WABCO brand, with 6 pcs big brake chamber
Tire: 12.00R20, 12R22.5, 315/80R22.5 etc. LINGLONG or TRIANGLE brand
Suspension: mechanical type, with 120x16mmx10pcsx6sets leaf spring.
Size: 7500x2500x3000mm
Cargo Box Size: 7000x2300x1500mm, bottom 8mm, side 6mm
The Specification Only For Your Reference, We Could Accept The Custom Made.
