Container semi trailer is fairly used for the warehouse and terminal, with the protect goods safety etc advantage.
The self-weight of the container semi-trailer reaches about 4 tons-5.2 tons, using high-strength steel
to reduce its own weight. High-strength steel semi-trailers are lighter than ordinary carbon steel light
semi-trailers; using high-strength steels, the semi-trailers are optimized for design, without changing
the semi-trailer load capacity, the semi-trailer's self-weight is reduced by more than 1.3 tons, which
can be effective Increase the efficiency of vehicle use.
3 Axles Container Flatbed Semi Trailers
The Main Specification For The Container Semi Trailer.
Dimension: 12400mm*2500mm*1575mm(Size can be choose freely)
Loading Capacity: 30T-50T
Axle: 13T/16T,FUWA/BPM Brand
Rim: 9.00-22.5/8.00-20/8.5-20
Tire: 12.00R22.5, 315/80R22.5, 11.00R20,12.00R20 Brand can be Optional
Suspension: Mechanical suspension(Germany Type or America Type)or Air suspension
Spring leaf: 120(W)mm*16(Thickness)mm*10 Layer(especial for exporting market)
King pin: JOST brand 2.0 or 3.5 inch
Support leg: JOST brand
Main beam:
Height:500mm,upper plate is 14mm,middle plate is 8mm,
Down plate is 16mm; Material is Q345B Steel.
Side beam 16mm channel steel(Material is Q235steel).
Bottom platform 3mm diamond steel plate
Brake chamber: WABCO RE 6 relay valve;T30/30+T30 Spring brake chamber; Two pieces of 45L air tanks
