Dump semi-trailer is a semi-trailer suitable for the transportation of bulk cargo such as coal, ore, earthwork, and building materials.
Self-unloading semi-trailers are suitable for the transportation of bulk cargo such as coal, ore, and building materials.
1. The carriage adopts side-turning and back-turning self-unloading methods, which can effectively load and unload the machine to transport bulk cargo.
2. Both the frame and the longitudinal beam of the carriage are welded with high-quality manganese plates, and the cargo box has two types: dustpan and rectangle. It has high strength, strong lifting force, good rigidity, toughness, strong bearing capacity, and no permanent deformation.
3. Sophisticated technology: the main components are processed by advanced equipment, the longitudinal beams are fully automatic submerged arc welding, and the assembly machine is used for precise assembly of the wheel axle and the steel plate spring.
Tipper Trailer Vehicles:
| Model No. | TMA360TO110DT |
| Axles | FUWA 13T*3 |
| Landing | JOST E100 |
| King Pin | JOST 90# |
| Tires | TRIANGLE 13R22.5 12 Pcs |
| Main Beam | Top flange 12mm Middle 8mm Lower flange 14mm |
| Brake valve | WABCO |
| Painting | 2 coats after ball blasting |
| Cargobox | 9500*2300*1500mm,Front lifting HYVA pump |
| Kurb Weight | 13Tons |
