A semi-trailer that carries cargo in an open (flat) or closed (van) cargo space.
-. With 12 pcs twist lock and 24 pcs rope tightener.
-. High strength steel with automatic welding for main parts.
-. Total 28 tons landing gear.
-2. 60 Tons Fence Semi Trailer Main Specification.
Product Name: Fence Semi Trailer
Loading Weight: 60,000kg
Tare Weight: 8,500kg
Axle: 3 axle, 3x13 tons
Suspension: America type, 8mm thickness
Leaf Spring: 90x16mmx10pcsx6sets
Rim: 16mm thickness
Tire: 12R22.5, 12 pcs linglong brand
Brake System: WABCO brand, ABS and 6 pcs brake chamber
Thickness Of Frame: Upper plate 14mm, middle 8mm, lower plate 16mm, “I” type main beam
Material: Q345, high strength steel
Other: With 12 pcs twist lock and tool box
Cargo Box: 12300x2300x800+600mm, side wall 1.5mm, bottom plate 3mm thickness.
Dimension: 12500x2500x3400mm
