TRUCKMAN Brand 3 Axles Dump Semi Trailers

TRUCKMAN Brand 3 Axles 60 Tons Dump Semi Trailer Applications:

Dump Semi Trailer can be divided into two categories according to their uses: one type of heavy-duty and super-heavy dump trailers for off-road transportation are mainly responsible for transportation tasks such as large-scale mines and engineering, and they are usually used in conjunction with excavators. The other type of light and medium-sized ordinary dump trailers used for road transportation are mainly responsible for the transportation of loose goods such as sand, soil, and coal, and they are usually used in conjunction with loaders.

1. The carriage adopts side-turning and back-turning self-unloading methods, which can effectively improve the transportation efficiency of the loader to transport the bulk cargo.
2.  Both the frame and the longitudinal beam of the carriage are welded with high-quality manganese plates, and the cargo box has two types: dustpan and rectangle. It has high strength, strong lifting force, good rigidity, toughness, strong bearing capacity, and no permanent deformation.
3.  Sophisticated technology: the main components are processed by advanced equipment, the longitudinal beams are fully automatic submerged arc welding, and the assembly machine is used for precise assembly of the axle and steel plate spring.

TRUCKMAN Brand 3 Axles 60 Tons Dump Semi Trailer Specs:

Model: TMA360TO110DT

Deadweight: 60 tons

Axle model: 13T*3, ​​FUWA brand

Tyre model: 12R22.5, LINGLONG brand

Outrigger model: JOST 28T, double speed

Cargo box: bottom 8mm and side 6mm, front lifting Hyva brand Cylinder

Traction pin: JOST 90#

Beam: upper 14mm, middle 8mm, lower 14mm

Material: Q345

Vehicle size: 11500*2500*3400mm

Spare tire rack: 2 pcs, tool box: 1 pcs

Anti-rust treatment: shot blasting, electrophoresis

Spray paint: 2 top coats, one base coat
